BA-56EEXENT

Loudspeaker, Flush, 6W 100V, Ceiling

Ceiling loudspeaker for hazardous areas
100V line transformer
ATEX approved
1 x M20 EExe ATEX approved cable gland and 1 x M20 EExe ATEX approved blind plug
Adjustable power tapping 0,3 W - 0,5 W - 1,0 W - 1,5 W - 3,0 W - 6,0 W
Open the e-chamber by loosening the screws on the lid
Lead cable through cable gland and connect to screw terminal according required tapping.
If earthing, use the specially marked screws.
Fasten lid screws with a torque of 2-3 Nm to assure the IP rating.
Secure the loudspeaker to ceiling or wall by 3 screws (not enclosed).
Mount the grill to the speaker with 3 screws (enclosed).
For optimum performance, always use the correct voltage / power and operate within the frequency limits as stated.
Use only certified / specified cable glands and blanking plugs.
Do not open the loudspeaker when energized.
